Zoll X Defibrillator Features
Weighing under 12 pounds, the Zoll X Series Defibrillator is full-featured and designed to be effective for all patients, including neonates. Transporting a critically ill patient through the hospital requires a lightweight device with extensive monitoring capabilities. And that’s exactly what you get with the Zoll Defibrillator X Series, plus defibrillation and real-time CPR feedback in one compact device.

Capnography
Pulse oximetry
Three invasive pressures
Two temperature channels
Non-invasive blood pressure
Zoll X Defibrillator Specifications

General
Weight: 11.7 lbs. (5.3 kg) with battery and paper
Dimensions: 8.9 in (22.6 cm) x 10.4 in (26.4 cm) x 7.9 in (20.1 cm)

Enclosure Protection
Solid Foreign Object: IEC 60529, IP5X
Water: IEC 60529, IPX5
Operating Conditions
Temperature: 0 to 50°C
Humidity: 15 to 95% RH (non-condensing)
Vibration: MIL-STD 810G, Method 514.6, 4.4.2 Procedure II EN ISO 9919 (per IEC 60068-2.64) EN 1789 for an ambulance. RTCA/DO-160G (multiple helicopter frequencies)
Shock: IEC 60068-2-27, 100g, 6 ms half-sine
Drop: EN 1789, 30-inch functional drop, IEC 60601-1, tested at 2 meters
Altitude: -170 m to 4572 m (-557 feet to 15,000 feet)

Monitor / Display
Size: 6.5 in (16.56 cm) diagonal
Input: 3-lead, 5-lead, or 12-lead patient cable, paddles, or multifunction electrodes
Type: Color LCD, 640 x 480 pixels, 800 MCD
Sweep Speed (user selectable): 25 mm/sec or 50 mm/se
Lead Selections: Paddles (Pads), I, II, III, AVR, AVL, AFV, V1-6

Frequency Response (user selectable)
0.67 – 20 Hz Limited mode
0.67 – 40 Hz Monitor mode
0.25 – 40 Hz Filtered diagnostic mode
0.05 – 150 Hz Diagnostic mode

Defibrillator
Waveform: Rectilinear Biphasic
Energy Selections: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 30, 50, 70, 85, 100, 120, 150, 200 joules
Energy Display: Display indicates selected and delivered energy
Charge Time: Less than 7 seconds with a new, fully charged battery
Charge Controls: Front panel and on apex paddle
Pads/Paddles: Hands-free pads and external adult and pediatric paddles. Adult paddles slide off to expose pediatric paddles.
Synchronized Mode: Synchronizes defibrillator pulse to the patient’s R wave. “SYNC” message displayed on monitor and markers shown on both monitor and recorded ECG. Meets Clause 104 of AAMI DF80.
