Erbe ICC 300

ERBE Erbotom ICC 300 Features
The ERBE ICC 300 is a high-frequency surgical unit for cutting and coagulation. It’s the price-conscious solution for medium and major surgical procedures. After all, smooth routine in the operating room depends on maximum safety, a high degree of comfort in use, and perfect functionality – exactly the features of the ICC 300. And it also meets the special demands of Minimally Invasive Surgery.

CUT CONTROL for automatically perfect cuts.Reproducible cut quality with minimum necrosis
high CUT with specialized arc regulation for underwater cuts or in fatty structures
SOFT coagulation for precisely controlled coagulation
No carbonization (SOFT COAG)
Far less adhesion and electrode soiling
Bipolar coagulation for even greater safety
PPS for intelligent support of initial incisions and cutting
AUTO START for the greater facility of bipolar coagulation
SPRAY coagulation for better surface effects
ARGONPLASIVIA coagulation via an integrated plug-in connection
ERBE Erbotom ICC 300 Specifications

Dimensions
Dimensions (HxWxD) cm, (In) (Display) 41 x 15.2 x 36.8 (16.1 x 5.9 x 14.5)
Weights, kg (lb) (Display) 10 (22)

Electrical
Monopolar (Systems) Cut(blend), coagulate
Max. energy output ( at rated ohms) (SYSTEMS) More than 250 Watt 300
Max voltage, VP-p (Systems) 1200
Max. energy output ( at rated ohms) (SYSTEMS) Up to 150 Watt 120
Max voltage, VP-p (Systems) 380 soft, 5,600 spray
Bipolar (SYSTEMS) Coagulate
Max. energy output ( at rated ohms) (SYSTEMS) Up to 150 Watt 120
Max voltage, VP-p (Systems) 380
